Septentrio AsteRx2e Packaged Receivers

This product has been discontinued by the manufacturer. Please see the related product(s) for replacement options or contact us.

The AsteRx2e receiver family provides all-in-view dual-frequency GPS/GLONASS receivers for demanding industrial applications.

SKU: AsteRx2e Receivers Categories: , , , Manufacturer: Septentrio

AsteRx2e Packaged Receivers

This product has been discontinued by the manufacturer. Please see the related product(s) for replacement options or contact us.

The AsteRx2e receiver family provides all-in-view dual-frequency GPS/GLONASS receivers for demanding industrial applications. As member of the AsteRx-family of compact OEM boards, AsteRx2e features proven high-quality all-in-view GPS and GLONASS tracking and Septentrios advanced multipath mitigation algorithm APME, offering cm-level measurement quality for high precision positioning, even in challenging environments.  Terrastar-D Service is available for the AsteRx2eL HDC.

Main Features
* 136 hardware channels
* Up to 25 Hz data output rate
* A Posteriori Multipath Estimator technique (APME)
* Receiver Autonomous Integrity Monitoring (RAIM)
* Differential GPS (base station and rover)
* Compact OEM board and housed solutions
* Includes intuitive GUI (RxControl) and detailed operating and installation manual


Ax2e_GLO     P2092     Upgrade of GPS-only configuration with GLONASS capabilities

Ax2e_RTK      P2002     RTK + Moving Base option (RTK base/rover) (incl. DGPS)

Ax2e_BASE    P2012     Outputs RTK Base corrections

Ax2e_Event    P2022     Event Marker option (2 marker inputs)

Ax2e_ETH       P2042     Ethernet option (AsteRx2eH/Asterx2eL, incl. CBLe_ETH_MX in housed version)

Ax2e_LOG      P2032     Enables logging functionality

Ax2e_HHW      P2132     Upgrade from single antenna to dual antenna operation (AsteRx2eH OEM_HW / PRO_HW only)

Ax2e_HDG       P2122     Heading option (AxteRx2eH OEM_HW / PRO_HW only)


AsteRx2e HDC_L1
400032B1032     Single Frequency version of AsteRx2e, GPS only configuration,
upgradable to dual-frequency, in high-impact Hard Case housing

AsteRx2e HDC_L1G
400032B1033     Single Frequency version of AsteRx2e, GPS/GLO configuration,
upgradable to dual-frequency, in high-impact Hard Case housing

AsteRx2e HDC
400032B1034     Dual frequency GPS/GLONASS receiver, GPS only configuration,
in high-impact Hard Case housing

AsteRx2eL HDC
400059B1042     Dual frequency GPS/GLONASS/L-Band housed receiver
(PPP included), GPS only configuration, in high-impact Hard Case housing -
Terrastar Service available for this model only

AsteRx2eH PRO
400039B1084     Dual frequency GPS/GLONASS Heading receiver
GPS/GLONASS configuration, in aluminum housing

AsteRx2eH PRO_HW
400039B1082     Dual-Frequency GPS/GLONASS receiver, in aluminum housing,
GPS single antenna configuration
